Electrical Parameters At Standard Test Conditions
| Model of modules | SP315-60M | SP320-60M | SP325-60M | SP330-60M | SP335-60M | SP340-60M |
| Power (Pmax/W) | 315 | 320 | 325 | 330 | 335 | 340 |
| Maximum power voltage (Vmp) | 33.2 | 33.4 | 33.6 | 33.8 | 34 | 34.2 |
| Maximum power current (Imp) | 9.49 | 9.59 | 9.67 | 9.76 | 9.85 | 9.94 |
| Open circuit voltage (Voc) | 40.7 | 40.9 | 41.5 | 41.8 | 42.2 | 42.6 |
| Short circuit current (Isc) | 10.04 | 10.15 | 10.17 | 10.25 | 10.32 | 10.38 |
| Module efficiency | 18.88% | 19.18% | 19.48% | 19.78% | 20.08% | 20.38% |
STC ( Electrical parameters at standard test conditions. STC: AM=1.5, 1000W/m², Cells Temperature25℃ )
Electrical Parameters At NMOT Test Conditions
| Electrical Parameters at NMOT Test Conditions | ||||||
| Front power Pmax/W | 234 | 238 | 242 | 245 | 249 | 257 |
| Maximum power voltage (Vmp) | 30.8 | 31 | 31.4 | 31.77 | 31.9 | 32.7 |
| Maximum power current (Imp) | 7.59 | 7.68 | 7.69 | 7.75 | 7.81 | 7.86 |
| Open circuit voltage (Voc) | 37.8 | 38 | 38.6 | 38.9 | 39.2 | 40.1 |
| Short circuit current (Isc) | 8.12 | 8.2 | 8.22 | 8.28 | 8.34 | 8.39 |
NMOT ( Irradiance 800W/m²，Ambient Temperature 20℃,AM1.5,Wind Speed 1m/s )
Mechanical Data
| Module size (L*W*H) | 1665×1002×35mm |
| Weight | 17.4kg |
| Cell | 60 cells, Mono-Crystalline PERC, 158.75mm × 158.7mm |
| Front glass | 3.2mm ultra clear embossed semi-tempered coated glass |
| Frame | Anodized aluminum alloy |
| Junction box | IP68 |
| Output wire | 4mm² |
| Wire length | Line length 900mm |
| Connector | MC4 Compatible IP68 |
| Packing Specification | 31 pcs/Pallet; 868pcs/40′ HQ |
